Part No.AIMB-G501
-
-
Form Factor
Form Factor
NANO-ITX
-
Processor
CPU
Intel Celeron J4125
BIOS
AMI BIOS
Core Number
4
CPU TDP
10W
Frequency
2.0GHz~2.7GHz
L3 Cache
4MB
-
Memory
Technology
DDR4
Max.Capacity
LPDDR4 up to 8GB
Socket
LPDDR4 EMMC
-
Display
Controller
Intel UHD Graphics 600
Video Interface
1*HDMI
-
Ethernet
Speed
867 Mbps
Controller
intel AC7265 WIFI 2.4G/5G,WiFi 802.11ac/a/b/g/n
-
Audio
Audio Interface
HD Audio
CODEC
everest ES8316
Connector
1(HP_OUT/MIC_IN)
-
WatchDog Timer
WatchDog Timer
Yes
-
I/O
USB
2*USB3.0
TPM
Support
-
Storage
M-SATA
1*M.2 M key Type2242 For SSD(SATA/NvMe)
-
Power
Power type
DC Type-C 12V
Connector
DC Type-C jack
Power Adaptor
Yes
-
Environment
Non-Operational Temperature
"-10℃~60℃"
Operational Temperature
"-10℃~60℃"
-
Physical
Dimension
55mmX55mm
Weight
33g
Construction
with cooling fan
-
Operating System
Microsoft Windows
Yes,WIN10/WIN11
Linux
NO
-
Form Factor
AIMB-G501
NANO-ITX
-
CPU
AIMB-G501
Intel Celeron J4125
-
BIOS
AIMB-G501
AMI BIOS
-
Core Number
AIMB-G501
4
-
CPU TDP
AIMB-G501
10W
-
Frequency
AIMB-G501
2.0GHz~2.7GHz
-
L3 Cache
AIMB-G501
4MB
-
Technology
AIMB-G501
DDR4
-
Max.Capacity
AIMB-G501
LPDDR4 up to 8GB
-
Socket
AIMB-G501
LPDDR4 EMMC
-
Controller
AIMB-G501
Intel UHD Graphics 600
-
Video Interface
AIMB-G501
1*HDMI
-
Speed
AIMB-G501
867 Mbps
-
Controller
AIMB-G501
intel AC7265 WIFI 2.4G/5G,WiFi 802.11ac/a/b/g/n
-
Audio Interface
AIMB-G501
HD Audio
-
CODEC
AIMB-G501
everest ES8316
-
Connector
AIMB-G501
1(HP_OUT/MIC_IN)
-
WatchDog Timer
AIMB-G501
Yes
-
USB
AIMB-G501
2*USB3.0
-
TPM
AIMB-G501
Support
-
M-SATA
AIMB-G501
1*M.2 M key Type2242 For SSD(SATA/NvMe)
-
Power type
AIMB-G501
DC Type-C 12V
-
Connector
AIMB-G501
DC Type-C jack
-
Power Adaptor
AIMB-G501
Yes
-
Non-Operational Temperature
AIMB-G501
"-10℃~60℃"
-
Operational Temperature
AIMB-G501
"-10℃~60℃"
-
Dimension
AIMB-G501
55mmX55mm
-
Weight
AIMB-G501
33g
-
Construction
AIMB-G501
with cooling fan
-
Microsoft Windows
AIMB-G501
Yes,WIN10/WIN11
-
Linux
AIMB-G501
NO
